Saturn
Personal Breath Alcohol Analyzer Mercury
Technical Data Sheet
Fuel Cell Sensor
Advanced fuel cell technology for accurate alcohol detection
Color Touch Screen
2.4" TFT colour touch screen for clear results display
Extensive Memory
Stores 16,000 test records including all information
Wireless Printing
Bluetooth connectivity for thermal or DOT matrix printers
Long Battery Life
Over 3000 tests with 4 AA alkaline batteries
Multiple Units
BrAC: mg/L, BAC: gm%, mg/mL, mg/100mL, or other units
Specification
| General Specifications | |
| Sensor | Fuel Cell |
| Working Temperature | -10°C to 50°C |
| Storage Temperature | -25°C to 70°C |
| Battery Life | Over 3000 tests |
| Battery | 4 AA alkaline batteries |
| Display LCD Size | 2.4" TFT colour touch screen |
| Weight | 256g included batteries |
| Size | 145 x 66 x 33 mm |
| Sampling System | Automatically or manually take a deep lung sample |
| Optional Power | Supply 12 volt car adapter or AC 6 volt adapter |
| Clock | Real time clock |
| Units of Measure | BrAC: mg/L, or other units BAC: gm%, mg/mL, mg/100mL, or other units |
| Detection Specifications | |
| Detection Range | 0.00% BAC to 0.63% BAC |
| Accuracy | 0 - 0.10%BAC: ±5% 0.10 - 0.15%BAC: ±8% 0.15 - 0.63%BAC: ±10% |
| Data & Connectivity | |
| Memory | 16,000 tests records including all information |
| Connection Port | USB |
| Printer | Bluetooth printer: Thermal or DOT Matrix |
| GPS (Optional) | ±5M |
Wireless Printer Specifications
| Model | WPT-ZR |
| Size | 12cm x 8cm x 3.5cm |
| Weight | 200g with battery |
| Battery | 7.4V 2,000mAh Ni-MH rechargeable battery |
| Battery Life | 300 printouts |
| Thermal paper size | 5.7cm X 560cm |
| Other Features | Easy-load paper |
